About the Open QRP Transceiver

I am excited to have the opportunity to carry on for K1EL's terrific OpenQRP transceiver kit. This has been in development over the past few years and I was a beta builder as well having built several versions. This is a solid transceiver and has many bells and whistles including:

  • Single Band : 40 meters (other bands with component changes)
  • Tuning range: 60KHz minimum via varactor diode
  • Tuning Control 10K 10 turn potentiometer
  • Receiver Incremental Tuning, Fine Tune Option
  • Mode: CW only
  • Receiver MSD: TBD uV
  • Four crystal IF filter with 690 Hz center frequency
  • IF Selectivity: 400 Hz
  • 4 pole audio active bandpass filter
  • Receive current: Active: 50 ma No signal: 30 ma
  • Transmitter: Final Amplifier IRF510 MOSFET, 6-8 watts output at 13.5 volts
  • Transmitter current: 1.100 A (40 M) at 8 watts.
  • Spurs: TBD dBc maximum
  • CPU: ATmega168 @ 16.384 MHz based on Arduino microcontroller platform
  • Open source software, written entirely in 'C'
  • In-circuit programming (ICSP)
  • 5 to 55 wpm internal iambic keyer, Iambic A and B, keyer emulation modes
  • Six message memory slots
  • Six Pushbutton inputs
  • 16 character by 2 line LCD display
  • Frequency readout 100Hz resolution
  • Relative signal strength indicator
  • Built in CW decoder
  • Power supply voltage readout
  • Front panel controls: Tune, RIT, and RF gain
  • On board trimmers: AF gain trim, LCD Contrast trim, Tx Drive adjust
  • Coax 50 ohm output, modular BNC jack
  • 1/8" Jack inputs for Iambic Paddle and Audio output (stereo headphones)
  • 2.5mm Power Supply jack
  • PC Board Size: 4.5" wide X 5.0" deep
  • Painted Aluminum Enclosure with silkscreened legends
  • Power supply voltage: 9 volts minimum, 16 volts maximum.


Supporting Files

Assembly Manual

Parts By Section

Bill of material/Inventory

Schematics


Kit Availability

For this initial run of 25 kits I will only be shipping to US and Canada addresses. Please note that Kanga Products UK is also kitting this transceiver in the UK.

The cost of this kit is $150.00 plus $10.00 shipping via priority mail. To order the kit:


Open QRP 40m Transceiver: $160.00
View your PayPal cart:



For more information about the kit or availability you may contact me at:
Subscribe to the openQRP group
Powered by groups.yahoo.com


Background from K1EL

Over the past couple of years I have been fascinated by the Open Source software revolution. There are countless examples of how the open sourcing of software has fostered the development of exceptionally good free software applications. I would like to present an experiment to see if it’s possible to develop ham radio equipment by a community of radio amateurs who exchange ideas on the Internet.

I will kickstart the idea by presenting a microprocessor controlled QRP transceiver design and open the design up in a form that anyone can download, modify, and improve. It is expected that if you participate that you will, in return, share your ideas and work with others on the group. This website will provide a forum for this purpose as well as a means to upload your design files.

One astounding result of open sourcing is the appearance of free hardware and software design tools that are of exceptional quality. All the design work for the openQRP transceiver has been done on tools that can be downloaded and used with no cost or restrictions.

The software design used in the transceiver will be covered under an open source license that applies specifically to software.

The hardware designs presented here share the principles of free and open-source software. All of us can learn from each other by sharing concepts and ideas. To make this happen I have released original design files in open formats. These files are licensed under a Creative Commons Attribution Share-Alike license, which allows for both personal and commercial derivative works, as long as they credit openQRP and release their designs under the same license. It is important to note that the Arduino CPU design, incorporated in the openQRP transceiver, is covered by Arduino’s own license.

As I mentioned above, my plan is to present a transceiver design and document the development and debug. As I write this I am in the middle of debugging it and I will present all the details (both good and bad) in the Blog section of this site (Project Progress). I think there is just as much learned by studying mistakes as there is by studying success. When it’s complete I will offer blank PC boards and parts kits at a minimal cost. Of course you can build your own copy any way you would like, that’s part of the deal.

A word about firmware. (I like to refer to software that controls a piece of hardware as firmware). The firmware that controls the transceiver runs on an Atmel microprocessor. I use Arduino as the firmware development platform. I quote from their website: “Arduino is an open-source electronics prototyping platform based on flexible, easy-to-use hardware and software” I support ‘on board microcontroller programming’ on the transceiver PCB so that anyone can write software for it and then download it into the board. The source for the basic transceiver control firmware will be available for free download just like the PCB design files.

The final radio package is close to completion, I am in the final stages of documentation now. The development of the radio is covered in the “Project Progress” Blog. To view, click on the Project Progress tab and browse back through installments that go back well over a year.

73

Steve K1EL
